Nestled in the heart of Manama’s vibrant industrial landscape, Ahmer Steel stands as a trusted partner for demanding projects. We take pride in sourcing and supplying high-performance materials like Alloy Steel Grade 9 Coil, a product engineered for resilience. Our team understands that behind every specification is a critical application, which is why we ensure our clients receive material that consistently meets the stringent challenges of high-pressure and high-temperature environments, backed by our commitment to quality and reliable service.
The strength of Alloy Steel Grade 9 Coil comes from a carefully balanced composition, primarily chromium and molybdenum. This blend gives the steel its notable mechanical properties, including excellent tensile strength and good ductility. It maintains these characteristics even when exposed to elevated temperatures, offering superior resistance to creep. This combination of toughness and the ability to withstand thermal stress makes it a go-to material for engineers facing demanding operational conditions.
| Specifications | : | ASTM A387 / ASME SA387 |
| Thickness | : | 1mm-300mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, 4050mm etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm, 15000mm etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| Alloy Steel Gr 9 | 0.15 max | 0.30-0.60 | 1.0 max | 0.030 max | 0.030 max | 8.0 – 10.0 | 0.90 – 1.10 | – | – |
| Tensile (MPa) | Yield (MPa) | Elongation (50mm) | Elongation (200mm) | Reduction of Area |
| 415 – 585 | 205 min | 18% min | – | 40% min |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel based in Manama, Bahrain is a trusted manufacturer and supplier for Alloy Steel Grade 9 Coil of great quality. In fact, we have earned our reputation for providing a variety of top-notch steel products-such as Structural Steel, Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel-with emphasis on Structural Steel Sheets and Plates. Basic product lines include a complete range of Pipes, Tubes, Flanges, Forged Fittings, Bars, and other forms. Jaxon Steel is committed to its delivery and customer service, thus ensuring that they procure the best raw materials to guarantee high strength and durability with performance specifically for critical industrial applications. Contact us anytime for your Structural Steel Sheet and Plate needs!
You’ll typically find this robust coil at work in some of the most critical systems. Its primary applications are in power generation plants and petrochemical refineries, where it’s expertly fabricated into essential pressure-containing components like tubing and piping. It’s also the material of choice for heat exchangers and boiler systems, where constant exposure to high heat and corrosive elements is a given. Essentially, wherever there’s a need for reliable performance under substantial stress, Alloy Steel Grade 9 provides a dependable and long-lasting solution.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
