Ahmer Steel, based in the vibrant industrial hub of Manama, Bahrain, stands as your trusted partner for robust and reliable steel solutions. We are pleased to supply the high-performance ASTM A709-50W Corten steel sheet and plate, a material celebrated for its exceptional resilience. This steel is engineered for demanding environments, offering superior strength and a unique, self-protecting quality that makes it ideal for enduring the test of time and the elements in both structural and aesthetic applications throughout the region.
The composition of ASTM A709-50W Corten includes elements like copper, chromium, and nickel, which work in harmony to develop its distinctive protective patina. Mechanically, this grade is defined by its high yield strength of 50 ksi minimum, alongside excellent toughness and weldability. This combination ensures the material can withstand significant stress and impact, guaranteeing structural integrity and long-term performance in challenging conditions where ordinary steel would succumb to corrosion.
STANDARD:Â ASTM A709
THICKNESS:Â 6-100mm
WIDTH:Â 900-4800mm
LENGTH:Â 3000-12000mm
GRADES:50W,50WT,50WF
SERVICES: Welding, Forming, Thermal Cutting
| TYPE | THICKNESS (in) | MN (wt %) | C (MAXÂ wt %) | S (MAXÂ wt %) | NI (MAXÂ wt %) | P (MAXÂ wt %) | V (wt %) | SI (wt %) | CR (wt %) | CU (wt %) |
|---|---|---|---|---|---|---|---|---|---|---|
| B | 2.00 – 3.00 | 0.75 – 1.35 | 0.20 | 0.030 | 0.50 | 0.030 | 0.01 – 0.10 | 0.15 – 0.50 | 0.40 – 0.70 | 0.20 – 0.40 |
| A | 0.1875 – 2.00 | 0.80 – 1.25 | 0.19 | 0.030 | 0.40 | 0.030 | 0.02 – 0.10 | 0.30 – 0.65 | 0.40 – 0.65 | 0.25 – 0.40 |
| GRADE | THICKNESS (in) | ELONGATION IN 8″ 2) (MIN %) | TENSILE STRENGTH (MIN ksi) | YIELD STRENGTH 1) (MIN ksi) | ELONGATION IN 2″ 2) (MIN %) |
|---|---|---|---|---|---|
| 50WT | 0.1875 – 3.00 | 18 | 70 | 50 | 21 |
| 50W | 0.1875 – 3.00 | 18 | 70 | 50 | 21 |
| 50WF | 0.1875 – 2.50 | 18 | 70 | 50 | 21 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Ahmer Steel is one of the most prominent manufacturers and suppliers of superior quality ASTM A709-50W Corten Steel Sheet and Plate in Manama, Bahrain. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.Â
| GRADE | THICKNESS (in) | MIN LONGITUDINAL INDIVIDUAL VALUEÂ 1) (ft-lbs) | MIN LONGITUDINAL AVERAGE ENERGYÂ 1) (ft-lbs) | ZONE 2 TEST TEMP | ZONE 1 TEST TEMP | ZONE 3 TEST TEMP |
|---|---|---|---|---|---|---|
| 50WT | 2.01 – 3.00 | — | 20 | 40 oF | 70 oF | 10 oF |
| 50WT | 0.1875 – 2.00 | — | 15 | 40 oF | 70 oF | 10 oF |
| 50WF | 0.1875 – 2.00 | 20 | 25 | 40 oF | 70 oF | 10 oF |
| 50WF | 2.01 – 2.50 | 24 | 30 |
| GRADE | WIDTH (in) | THICKNESS (in) | LENGTH (in) |
|---|---|---|---|
| 50WT | 72 – 120 | 0.1875 – 3.00 | 240 – 1200 |
| 50W | 72 – 120 | 0.1875 – 3.00 | 240 – 1200 |
| 50WF | 72 – 120 | 0.1875 – 2.50 | 240 – 1200 |
The uses for this versatile steel are extensive, particularly in ambitious architectural designs, enduring bridges, and resilient industrial structures. Its beautiful, russet-colored patina not only provides a maintenance-saving protective layer but also adds a unique, modern aesthetic to building facades and public art. From robust shipping containers and heavy-duty equipment to landmark infrastructure projects, ASTM A709-50W is the go-to choice for creating durable, long-lasting assets that gracefully weather the harsh coastal and desert climates.
