Nestled in the heart of Manama’s industrial landscape, Ahmer Steel stands as a trusted name for robust and reliable piping solutions. We are proud to specialize in Carbon Steel F70 Forged Fittings, components engineered to meet the most rigorous demands. Our commitment lies in providing fittings that deliver exceptional performance and longevity, ensuring the integrity of critical systems for our clients across Bahrain and beyond. When you partner with us, you are choosing a supplier dedicated to quality and dependability, right here in the Kingdom.
The strength of these F70 fittings comes from their precise composition, primarily a balance of carbon and manganese, which creates a material known for its remarkable toughness. This specific grade is defined by its excellent mechanical properties, including a high yield strength of 70 ksi, which allows it to withstand significant pressure and stress without deforming. This combination of a resilient material structure and superior strength makes it an ideal choice for demanding high-pressure service environments where failure is not an option.
Standard :Ā ASTM A694 / ASME SA 694
Dimensions :Ā ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size :Ā 1/8″ NB to 4″ NB
Type :Ā Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure :Ā Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F70 | 0.06-0.10 | 0.20-0.40 | 1.10-1.40 | ā¤ 0.020 | ā¤ 0.010 | 1.20-1.70 | 0.20-0.40 | ā¤ 0.30 | ā¤ 0.25 | 0.02-0.06 | – |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 70 | 82 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F70 Forged Screwed Elbows, Street Elbow, Carbon Steel F70 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F70 Reducing Coupling, Carbon Steel F70 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F70 Threaded Bushing, Carbon Steel F70 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F70 Barrel Nipples, CS F70 Forged Threaded Boss, Carbon Steel F70 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F70 High Quality Socket weld 90Ā° Elbow, Straight and Reducing-on-the-Tees, Forged 45Ā° Short Radius Elbow, CS F70 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings ā Socket Welding, Threaded, and Buttwelding Ends | CS F70 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F70 Coupling |
Carbon Steel F70 Forged Fittings are the backbone of high-pressure systems in some of the most critical industries. You will find them forming secure connections in oil and gas pipelines, power generation plants, and petrochemical refineries, where they handle everything from steam and process fluids to hydrocarbon streams. Their innate durability also makes them perfect for shipbuilding and heavy industrial machinery. Essentially, in any application where safety and reliability under extreme pressure are paramount, F70 fittings provide the essential, trustworthy link.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
