Located in the heart of Manama’s industrial landscape, Ahmer Steel has built a reputation as a trusted partner for high-strength steel solutions. We are proud suppliers of DILLIDUR 450V sheets and plates, a material specifically engineered to meet the rigorous demands of challenging environments. Our team understands that your projects require durability you can count on, and we are committed to providing not just a product, but reliable expertise and service that supports Bahrain’s growing construction and manufacturing sectors from the ground up.
The strength of DILLIDUR 450V comes from its carefully balanced composition, which includes elements like nickel and chromium for enhanced toughness. This fine-tuned recipe gives the steel exceptional mechanical properties, most notably its high yield strength and excellent notch toughness, even at low temperatures. This means it can withstand significant impact and heavy loads without fracturing, a critical feature for structures exposed to intense stress or harsh climatic conditions where safety and longevity are non-negotiable priorities.
Item: Dillidur 450V
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| C | Si | Mn | P | S | Mo | Ni | Cu | Cr | V | Nb | B |
| ≤ 0.25 | ≤ 0.70 | ≤ 1.60 | ≤ 0.025 | ≤ 0.010 | ≤ 0.50 | ≤ 0.80 | ≤ 0.30 | ≤ 1.50 | ≤ 0.08 | ≤ 0.05 | ≤ 0.005 |
| Grade | Mechanical Property | Charpy V Impact Test | |||
| DILIDUR 450V | Yield | Tensile | Elongation | Degree | longitudinal |
| Min Mpa | Mpa | Min % | -20 | J | |
| 950 | 1400 | 11 | 35 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
Because of its remarkable resilience, DILLIDUR 450V is the go-to material for applications where failure is not an option. You will typically find it used in the construction of heavy-duty mining equipment, robust support structures for bridges, and in the demanding environments of earth-moving machinery. It’s also ideal for components in the material handling industry, such as large-scale hoppers and chutes, where its resistance to abrasion and impact ensures a longer, more reliable service life, reducing downtime and maintenance costs for your most critical operations.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
