Located in the industrial heart of Manama, Ahmer Steel stands as a trusted partner for high-strength steel solutions. We are proud to supply the exceptional DILLIMAX 690T sheets and plates, a material engineered for the most demanding projects. This high-strength, low-alloy steel represents the cutting edge of performance, offering an outstanding balance of strength and toughness that allows for lighter, more efficient designs without compromising on safety or integrity, making it an ideal choice for the region’s ambitious infrastructure and industrial developments.
The composition of DILLIMAX 690T is a carefully balanced formula of elements like carbon, manganese, and micro-alloys, which work in concert to deliver its remarkable properties. After a precisely controlled quenching and tempering process, it achieves a minimum yield strength of 690 MPa, ensuring exceptional load-bearing capacity. This is matched by impressive toughness, even in challenging low-temperature environments, and good weldability. This combination means you get a material that is not only incredibly strong but also practical and reliable to fabricate.
Grade : 70
Item : DILLIMAX 690T Structural Steel Plate
Thickness : 5 – 160mm, 6 – 60mm, 5 – 160mm
Width : 1000mm-4500mm
Length : 3000mm -18000mm
| C | Si | Мn | P | S | N | B | Сr | Сu | Мо | Nb | Ni | V |
| 0.20 max.(%) | 0.80 max.(%) | 1.70 max.(%) | 0.020-0.025 | 0.010-0.015 | 0.015 max.(%) | 0.005 max.(%) | 1.50 max.(%) | 0.50 max.(%) | 0.70 max.(%) | 0.06 max.(%) | 2.00 max.(%) | 0.12 max.(%) |
| Steel Grade | Thickness, mm | Yield strength, min MPa | Tensile strength, MPa | Elongation, min % |
| DILLIMAX 690T | ≥8 t ≤50 | 690 | 770-940 | 14 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
The uses for DILLIMAX 690T are as robust as the material itself, making it perfect for heavy-duty applications where failure is not an option. It is the go-to choice for constructing modern cranes, the booms of heavy excavators, and the frames of large mining trucks that endure constant stress. Beyond machinery, its high strength-to-weight ratio is invaluable in ambitious architectural designs, specialized transportation vehicles, and critical bridge components. By choosing this grade, engineers can create safer, longer-lasting, and more efficient structures that push the boundaries of what’s possible.
