Ahmer Steel, based in the industrial heart of Manama, Bahrain, has built a strong reputation for supplying premium-grade piping solutions tailored for demanding environments. We are proud to offer Low Temperature Carbon Steel A333 Gr 1 Pipe, a product engineered specifically for resilience where others might fail. This pipe is a cornerstone for industries that operate under extreme cold, providing essential reliability and safety for critical infrastructure projects.
The reliability of A333 Gr 1 pipe stems from its careful composition, primarily carbon, manganese, and silicon, balanced to resist brittleness in freezing conditions. Its true strength, however, lies in its excellent mechanical properties; it maintains impressive toughness and impact strength at temperatures plummeting to -50°C, ensuring it won’t become fragile. This combination of a robust chemical makeup and superior low-temperature performance makes it a trusted material for high-stakes applications.
| Type | Seamless / SAW / ERW / Spiral weld / Fabricated / Welded |
|---|---|
| Grade | Low Temperature Seamless Pipe: ASTM A333 Gr. 1 |
| Outer Dimensions | 19.05mm-457mm |
| Wall Thickness | 2.0mm-60mm |
| Lengths | required shall be specified on order.If no definite lengths required, following practice applies: |
| Single Random | 17′ ~ 24′ lengths |
| Double Random | 36′ ~ 44′ lengths |
| Additional Testing | NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, etc. |
| Compositions | Data |
|---|---|
| Carbon(max.) | 0.30 |
| Manganese | 0.40–1.06 |
| Phosphorus(max.) | 0.025 |
| Sulfur(max.) | 0.025 |
| Silicon | … |
| Nickel | … |
| Chromium | … |
| Other Elements | … |
| Properties | Data |
|---|---|
| Yield strength(min) | 205Mpa |
| Tensile strength(min) | 380Mpa |
| Elongation(%) | 35 |
| Nominal | OD mm | Pipe size | Sch. 30 | Sch20 | Schedule 40 | Sch.STD | Sch 60 | Strong (XS) | Schedule Extra | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Mm | Inch | Wall | Wt. | Wall | Wt. | Wall | Wt. | Wall | Wt. | Wall | Wt. | Wt. | Wall | |
| 3 | 10.3 | 1/8 | 1.73 | 0.357 | 1.73 | 0.37 | 0.47 | 2.41 | ||||||
| 6 | 13.7 | ¼ | 2.24 | 0.625 | 2.24 | 0.63 | 0.804 | 3.02 | ||||||
| 10 | 17.1 | 3/8 | 2.31 | 0.84 | 2.31 | 0.84 | 1.1 | 3.2 | ||||||
| 15 | 21.3 | ½ | 2.77 | 1.26 | 2.77 | 1.26 | 1.62 | 3.73 | ||||||
| 20 | 26.7 | ¾ | 2.87 | 1.68 | 2.87 | 1.69 | 2.2 | 3.91 | ||||||
| 25 | 33.4 | 1 | 3.38 | 2.5 | 3.38 | 2.5 | 3.24 | 4.55 | ||||||
| 32 | 42.2 | 11/4 | 3.56 | 3.38 | 3.56 | 3.39 | 4.47 | 4.85 | ||||||
| 40 | 48.3 | 11/2 | 3.68 | 4.05 | 3.68 | 4.05 | 5.41 | 5.08 | ||||||
| 50 | 60.3 | 2 | 3.9 | 5.44 | 3.9 | 5.44 | 7.48 | 5.5 | ||||||
| 65 | 73 | 21/2 | 5.16 | 8.63 | 5.2 | 8.63 | 11.41 | 7 | ||||||
| 80 | 88.9 | 3/8 | 5.5 | 11.3 | 5.5 | 11.3 | 15.3 | 7.62 | ||||||
| 90 | 1.6 | 31/2 | 5.74 | 13.57 | 5.74 | 13.57 | 18.63 | 8.08 | ||||||
| 100 | 114.3 | 4 | 6.02 | 16.07 | 6.02 | 16.07 | 22.3 | 8.56 | ||||||
| 125 | 141.3 | 5 | 6.55 | 21.77 | 6.6 | 21.77 | 30.9 | 9.53 | ||||||
| 150 | 168.3 | 6 | 7.11 | 28.26 | 7.11 | 28.26 | 42.5 | 10.97 | ||||||
| 200 | 219.1 | 8 | 7 | 36.8 | 6.35 | 33.3 | 8.2 | 42.5 | 8.2 | 42.5 | 10.3 | 53.1 | 64.6 | 12.7 |
| 250 | 273 | 10 | 7.8 | 51.3 | 6.35 | 41.7 | 9.27 | 60.3 | 9.27 | 60.3 | 12.7 | 81.5 | 81.5 | 12.7 |
| 300 | 323.9 | 12 | 8.4 | 65.2 | 6.35 | 49.7 | 10.3 | 79.7 | 9.53 | 73.8 | 14.3 | 109 | 97.4 | 12.7 |
| 350 | 355.6 | 14 | 9.53 | 81.3 | 7.92 | 68.1 | 11.13 | 94.3 | 9.53 | 81.3 | 15.1 | 126.4 | 107 | 12.7 |
| 400 | 406.4 | 16 | 9.5 | 93.3 | 7.92 | 77.9 | 12.7 | 123 | 9.53 | 93.3 | 16.7 | 160 | 123 | 12.7 |
| 450 | 457.2 | 18 | 11.1 | 122 | 7.92 | 87.8 | 14.3 | 156 | 9.53 | 105 | 19 | 206 | 130 | 12.7 |
| 500 | 508 | 20 | 12.7 | 155.1 | 9.53 | 117.2 | 15.1 | 183 | 9.53 | 177.2 | 20.6 | 248 | 155.1 | 12.7 |
| 550 | 558.8 | 22 | 12.7 | 171 | 9.53 | 129 | 9.53 | 129 | 22.2 | 294 | 171 | 12.7 | ||
| 600 | 609.6 | 24 | 14.3 | 210 | 9.53 | 141 | 17.4 | 255 | 9.53 | 141 | 24.5 | 355 | 187 | 12.7 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Ahmer Steel is a leading supplier of high-quality Low Temperature Carbon Steel A333 Gr 1 Pipe products in Manama, Bahrain. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
The primary use for this pipe is within systems that handle gases and liquids at frigid temperatures, making it indispensable for liquefied natural gas (LNG) plants and cryogenic storage facilities. Beyond the energy sector, you’ll find it in vital industrial refrigeration units, chemical processing plants, and pipeline systems located in arctic environments. Choosing A333 Gr 1 means investing in durability and operational safety for projects where failure simply is not an option.
