Located in the vibrant industrial heart of Manama, Ahmer Steel has built a reputation as a trusted partner for high-strength steel solutions. We take pride in supplying top-tier S690 QL sheets and plates, materials engineered to meet the most stringent demands. Our commitment is to provide not just a product, but a reliable foundation for ambitious projects across the region, offering the exceptional durability and performance that modern construction and manufacturing require. You can count on us for quality that stands up to the toughest challenges.
The composition of S690 QL steel is carefully balanced with elements like carbon, manganese, and micro-alloys, which work in concert to deliver its remarkable strength. Following a precise Quenched and Tempered heat treatment, these sheets and plates achieve a minimum yield strength of 690 MPa, ensuring exceptional resistance to heavy loads and impacts. This high strength is coupled with good toughness, even in challenging environments, making it a robust and dependable choice where structural integrity is absolutely non-negotiable.
Thickness :Â 5MM & Above
Width : 1500 – 3500mm
Length : 3000 – 18000mm
Grade :Â S690QL EN10137-2 EN10025-6:2004, A709-100, DILLIMAX 690, NAXTRA 70, WELDOX 700, E690, JFE HITEN 780LE, ALFORM 700
| Grade | C | Si | Mn | P | S | N | B | Cr | Cu | Mo | Nb* | Ni | Ti* | V* | Zr* |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S690 QL | 0.20 | 0.80 | 1.70 | 0.025 | 0.015 | 0.015 | 0.0050 | 1.50 | 0.50 | 0.70 | 0.06 | 2.0 | 0.05 | 0.12 | 0.15 |
| Designation | Mechanical Properties (ambient temperature) | |||||||
|---|---|---|---|---|---|---|---|---|
| Steel Name | Steel Number | Min. Yield Strength Reh MPa | Tensile Strength Rm MPa | Min. % elongation after fracture | ||||
| Nominal thickness (mm) | Nominal thickness (mm) | |||||||
| ≥3 ≤50 | ≥50 ≤100 | ≥100 ≤150 | ≥3 ≤50 | ≥50 ≤100 | ≥100 ≤150 | |||
| S690 QL | 1.8931 | 690 | 650 | 630 | 770/940 | 760/930 | 710/900 | 14 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
The exceptional strength-to-weight ratio of S690 QL sheets and plates makes them indispensable for heavy-duty applications. You’ll find this material at the core of demanding projects like the framework for high-rise buildings, sturdy bridges that span great distances, and the robust booms and arms of heavy mining and construction equipment. It’s also vital in the creation of crane parts, transportation vehicles, and offshore structures, where reducing weight without sacrificing an ounce of strength is crucial for both safety and efficiency. This steel truly builds the backbone of modern infrastructure.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
