A trusted name in Bahrain’s industrial landscape, Ahmer Steel proudly stands as a leading manufacturer and supplier of specialized steel plates from our base in Manama. We understand the critical demands of modern industry, which is why we specialize in supplying SA 516 GR.65N NACE HIC plates. This specific grade is engineered for resilience, offering exceptional protection against the challenging environmental conditions often found in oil, gas, and petrochemical applications, ensuring both safety and longevity for your most demanding projects.
The strength of SA 516 GR.65N NACE HIC plates lies in their carefully balanced composition and mechanical properties. They are forged with controlled chemistry, primarily carbon, manganese, and silicon, but with strict limits on impurities to resist cracking. This results in a robust material boasting high tensile and yield strength, combined with excellent notch toughness even at lower temperatures. This specific NACE HIC designation confirms its tested ability to withstand hydrogen-induced cracking in sour service environments, providing a reliable foundation for critical infrastructure.
| Grade | ASME SA 516 GR.65N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-460A/B | EN10028 P295GH | A/SA516 – Grade 65 | DIN 17155 17 MN 4 |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.65N NACE HIC Plates in Manama, Bahrain. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.65N NACE HIC Plates needs!
These specialized plates are essential for building equipment that operates in some of the most challenging environments. You’ll commonly find them used in the fabrication of pressure vessels, reactors, and distillation towers for the oil and gas sector. They are also crucial for constructing scrubbers and separators that handle sour gas containing hydrogen sulfide. Their proven resistance makes them the material of choice for any application where corrosion and hydrogen-induced cracking are serious concerns, ensuring operational integrity and safety for years to come.
